Description
About
The VeinOptix™ V7 Vein Finder is a portable, battery-operated medical device engineered to clearly visualize veins and
superficial blood vessels in real time. Its ergonomic diamond-head LED design gently stretches the skin surface,
ensuring smooth needle insertion and preventing vein rolling or collapse during venipuncture.
With optimized wavelength illumination and shadow-free optical technology, VeinOptix™ V7 delivers superior vein
visualization compared to traditional methods — making it the trusted choice of doctors, nurses, and phlebotomists
across hospitals and clinics.
Appearance
1. On–Off switch
2. Switch for intensity mode change
3. USB charging socket
4. Charging indication LED
5. LED window
6. Torniq Belt Grip
Directions to use :
- Use away from any overhead light sources (they may interfere with visualization).
- Hold the unit in position over the skin.
- Access the vein as placed.
- Touch pad must be in contact with the skin.
Technical Specifications :-
| Parameter |
Specification |
| Battery |
3.7 V, 800 mAh Li-ion |
| Brightness |
36 Lum |
| Intensity |
250 – 550 |
| Internal Diameter |
23 mm |
| Weight |
60 g |
| Origin |
Made in India |
Applications:
• Paediatrics
• Cardiology & Oncology
• Anaesthesiology
• Cosmetic & Dialysis Centers
Directions for Use:
- Use away from strong overhead lighting for best visibility.
- Hold the device gently over the target area — ensure full skin contact.
- Observe the illuminated vein pattern on the surface.
- Proceed with venous access (IV, blood draw, etc.) as indicated.
Charging Indicators:
• 🔴 Red Light – Charging
• 🟢 Green Light – Fully Charged
Warranty & Support
- VeinOptix™ V7 is backed by a one-year limited warranty.
- To activate your warranty, register your device on www.veinoptix.com.
- Physical damage or tampering voids warranty coverage.
Frequently Asked Questions (FAQ)
